Akashi is pre-1.0, so these APIs are usable but may change between minor releases before 1.0. Architecture tests classify every autoloadable Akashi declaration as an entry point, canonical model type, PHPStan diagnostic model type, exception, or explicitly internal declaration. This reference groups the public types by consumer workflow; autoloadability alone does not create an extension point.

Migrating from 0.1

Projects that build a corpus through MarkdownSource and execute or analyze it through the PHPUnit and PHPStan traits do not need code changes for 0.2. Existing Markdown fences, explicitly configured legacy marker comments, runtime directives, and text-based PHPStan expectations remain accepted.

Direct consumers of the canonical model need the following changes.

Example sources

Example now distinguishes inline documentation fences from canonical external PHP sources. Replace the removed properties as follows:

Use codeOrigin() whenever the maintained code location is sufficient. Inspect Example::$source only when the presentation distinction matters: InlineExampleSource carries the former fence location and metadata, while ReferencedExampleSource carries a canonical origin, optional named region, and one or more PHPDoc reference locations.

Code that directly constructed a 0.1 inline example should use Example::fromInline() with the former constructor arguments. The 0.2 constructor instead accepts an InlineExampleSource|ReferencedExampleSource and is intended for integrations that already model that distinction.

Manually constructed ExampleCorpus values must be ordered by canonical source path, first code line, and example ID. Corpora returned by MarkdownSource or DocumentationSource already satisfy this invariant.

PHPStan diagnostic expectations

DiagnosticExpectation::$text is now nullable because an expectation may constrain only a stable PHPStan identifier. Consumers reading the property must handle null. Existing new DiagnosticExpectation($text, $sourceLine) calls remain valid; the optional identifier and source-line range parameters are additive.

Directive::CompileOnly is a new enum case. Consumers using an exhaustive match over Directive must handle it. Trailing optional parameters added to AnalyzerDiagnostic, ExpectedException, and MetadataLocation do not require changes to existing calls.

No other 0.1 public type or member was removed. The change from native readonly classes to final classes composed only of readonly properties enables PHP 8.1 support without making model state mutable.

Source and Corpus

DocumentationSource is the ordinary entry point for mixed corpora; MarkdownSource remains the explicit Markdown-only entry point and exposes loadDocuments() for consumers that need the selected documents themselves.

Document, Example, and ExampleCorpus form the canonical public model. Example::$source is either Model\InlineExampleSource for a Markdown/PHPDoc fence or Model\ReferencedExampleSource for a canonical external PHP file or named region. Example::codeOrigin() returns the maintained code location without requiring callers to switch on that presentation distinction. A referenced source also retains each Model\ReferenceLocation where PHPDoc presents the canonical example. Typed integrations constructing inline examples can use Example::fromInline() to derive a matching CodeOrigin from one fenced SourceLocation.

Path, identifier, language, fence, directive, and source-coordinate values under jbboehr\Akashi\Model are also public because the canonical model and configuration objects expose them as typed state. That includes Model\ExpectedException, which carries a normalized authored throwable class name, optional nonempty case-sensitive message substring, and optional integer code without requiring the class to exist before runtime setup. Example::$expectedOutput carries an optional exact stdout byte string; null means no output contract, while an empty string explicitly requires silence. Public model constructors enforce the same invariants used by source discovery; these are data contracts, not subclassing or service-replacement seams.

The supporting value types are grouped by what they preserve:

Most consumers receive and inspect these values through the canonical model rather than constructing them directly. Direct construction remains supported for typed integrations that create documents or examples without weakening the model to raw arrays or ambiguous strings.

Synchronization

SynchronizationChecker::rewrite() replaces only stale code spans in memory. It preserves directives, fences, prose, Markdown or PHPDoc container prefixes, and the presentation’s line-ending convention, then re-parses and verifies the result against the already resolved canonical snapshot. The method performs no filesystem writes.

SynchronizationWriter::write() accepts the original loaded Document and its rendered replacement. It verifies the maintained bytes, rejects symbolic-link paths, and uses a flushed same-directory temporary file plus atomic rename. The writer preserves permission bits; callers that need validation across several documents should render the complete set before invoking it, as the CLI does.

Formatting

FormattingChecker::check() accepts an ExampleCorpus, skips every ReferencedExampleSource, and returns ordered mismatches for inline Markdown and PHPDoc fences. The checker runs a project-installed PHP-CS-Fixer against private temporary files through an argument vector. It ignores formatter-added file-level material outside the protected body, preserves authored opening tags, and does not write maintained source.

FormattingRewriter::rewrite() accepts the exact loaded Document and the mismatches belonging to it. It rejects referenced examples, stale or cross-document inputs, duplicate replacements, and formatter output that would terminate a Markdown fence or PHPDoc comment, change directive semantics, or otherwise fail re-extraction. A successful rewrite changes only the original code spans, restores their authored Markdown or PHPDoc prefixes, retains formatter-proposed line endings, and returns a new immutable Document; it performs no filesystem writes. Group mismatches by maintained document before calling the rewriter when a corpus spans several files.

The library operation remains separate from persistence. The CLI’s format --write mode groups mismatches by document, repeats the complete formatter pass to reject changed inputs or results, and then persists through the same stale-byte-protected atomic writer used by synchronization.

This is a concrete PHP-CS-Fixer integration, not a generic formatter extension point. External canonical examples remain ordinary PHP files and should use normal project formatter commands directly.

PHPUnit Runtime

Prepared-source, transform, executor, result, and failure types describe Akashi’s internal implementation boundary. They are not public extension points. Most runtime consumers should use VerifiesPhpUnitExamples; projects that need a custom PHPUnit method can use PhpUnitExampleDataSets and PhpUnitRuntime::assertExample() directly. Both paths keep skip and compile-only disposition, backend selection, preparation, execution, cleanup, and PHPUnit reporting within the supported facade.

PHPStan

AnalyzerDiagnostic, DiagnosticExpectation, DiagnosticAssignment, DiagnosticMatchResult, DiagnosticMismatchKind, DiagnosticsMatched, DiagnosticsMismatched, PhpStanJsonResult, and PhpStanVerificationResult form the public analyzer-independent result and matching model. AnalyzerDiagnostic::$ignorable is nullable because diagnostics built outside the JSON decoder may not carry that PHPStan-specific evidence. PhpStanVerificationResult partitions deterministic file results into typed matched and mismatched maps while preserving analyzer-wide errors; isSuccessful() requires no global errors and no file mismatches. DiagnosticExpectation can constrain an exact identifier, a message-or-tip substring, or both. Identifier directives also carry the maintained span of their associated PHP statement, which constrains the diagnostic line; legacy expectation source lines remain reporting metadata. An absent analyzer entry satisfies an explicit empty expectation list, so this result alone does not prove that a clean file was analyzed. Direct consumers may use these typed models with ExpectationParser, DiagnosticMatcher, PhpStanJsonDecoder, and PhpStanResultVerifier; the VerifiesPhpStanExamples trait remains the supported integration path for PHPStan’s runtime objects.

PhpStanCommandResult and PhpStanCommandTermination form the framework-neutral process model. A completed result always contains the raw exit status, including nonzero statuses; timeout, signal, and infrastructure failure carry only the evidence valid for that termination. A signaled result requires a positive signal and permits either no exit status or a nonzero platform-specific status; a successful zero status is rejected as contradictory. Standard output, standard error, and nonnegative elapsed nanoseconds are preserved for every result.

PhpStanCommandRunner accepts an explicit project root, executable, argument list, and finite positive timeout, which defaults to 60 seconds. It canonicalizes the root and executable with realpath(), inherits the caller’s environment, and never constructs or interpolates a caller-controlled command string. Symfony Process may retry a failed direct POSIX launch through an escaped shell command line without exposing that fact. A resulting 126 or 127 therefore remains a raw completed status; unavailable paths, local instrumentation failures, and process failures surfaced as exceptions become typed infrastructure evidence.

PhpStanCommandVerificationResult has three public variants. PhpStanCommandNotCompleted carries timeout, signal, or infrastructure evidence. PhpStanCommandOutputRejected carries completed command evidence and the JSON decode failure. PhpStanCommandVerified carries the completed command, decoded analyzer result, and diagnostic verification result; its name means verification completed, not that expectations matched. PhpStanCommandVerifier validates expectations before launching the command and returns one of these variants. It applies the same 60-second default timeout as the runner; callers may provide another finite positive duration. Nonzero completed statuses remain evidence rather than an automatic failure.

PhpStanExternalFixturePlan contains one canonical project root, a sorted nonempty list of project-relative .php analysis paths, and exactly one platform-native canonical absolute expectation-map entry for each path. PhpStanExternalFixturePlanner builds this model from examples selected by PhpStanExampleConfiguration. The corpus and configuration must describe the same canonical project root. The planner accepts referenced whole files and named regions, parses region expectations against the complete canonical PHP file while restricting directives and associated statement spans to the selected region, groups aliases of each physical file when the filesystem reports a stable device/inode identity, chooses one deterministic analysis path, and deduplicates overlapping expectations. It rejects selected inline examples, missing selections, empty expectation markers, or canonical files changed since corpus loading.

Exceptions

Source-loading failures, including malformed identity, runtime, reference, and named-region metadata, share Source\Exception\SourceException; transformation failures share Transform\Exception\TransformException; execution failures share Execution\Exception\ExecutionException; and PHPStan integration failures share Integration\PHPStan\Exception\PhpStanException. Formatting configuration, execution, output, rewrite, unsupported-input, and cleanup failures share Formatting\Exception\FormattingException. Synchronization structure, resolution, and persistence failures share Synchronization\Exception\SynchronizationException, which is also a source-exception subtype. The format --write CLI reuses SynchronizationWriter, so failures from its persistence boundary retain the synchronization exception family even though the application reports them as formatting command failures. Specific subclasses preserve distinctions such as missing paths, unsupported examples, runtime configuration, empty PHPStan selection, and verification infrastructure.

These exception families and their documented leaf classes are public machine-readable failure categories. Consumers should catch the narrowest meaningful type or its family base instead of parsing exception messages.

Malformed inputs passed directly to the analyzer-independent PHPStan model, PhpStanResultVerifier, or PhpStanCommandVerifier are programmer errors reported as \InvalidArgumentException, not PhpStanException instances. The same applies to malformed command paths, argument vectors, and timeout values; supported operational command failures are returned as PhpStanCommandResult or PhpStanCommandVerificationResult evidence instead of exceptions.

PhpUnitRuntime::assertExample() can also raise PHPUnit’s ordinary expectation-failure or skipped-test control flow.

Optional Dependencies

Core discovery, the domain model, transformation, execution, extraction, and synchronization do not require PHPUnit, PHPStan, or PHP-CS-Fixer to autoload. The Integration\PhpUnit namespace requires a compatible PHPUnit installation when used. Command execution, JSON decoding, and framework-neutral result verification need neither optional dependency; the caller supplies the executable it wants to run. PHPStan RuleTestCase verification requires both PHPUnit and PHPStan because it reports through PHPUnit. Formatting checks require a compatible project-installed PHP-CS-Fixer executable only when invoked; Akashi does not load its PHP classes.

See Compatibility and Safety for the targeted versions.
